Feedstock of Pellet Burner
Fuel type:wood pellet,peanut shell pellet,rice husk pellet,waste bacterium rod,nutshell...
Particle diameter:φ6-10mm
Nut shell size:<20%
Moisture content:<15%
Technical Parameters
|
Equipment model |
Equipment power (kw) |
Equipment size (L*W*H) (mm) |
Nozzle diameter and center height (mm) |
Biomass consumption (kg/h) | Heat value (kcal/h) | Reference weight (T) | Matched boiler capacity (T) |
| HQ-LK0.5T | 4.32 | 1900*900*1800 | 500*960 | 70 | 300,000 | 1 | 0.5 |
| HQ-LK1T | 4.32 | 1950*1310*2290 | 500*960 | 155 | 600,000 | 1.5 | 1 |
| HQ-LK2T | 8.95 | 2350*1700*2700 | 600*1160 | 310 | 1,200,000 | 2.5 | 2 |
| HQ-LK3T | 8.95 | 2500*1250*2800 | 600*1160 | 460 | 1,800,000 | 3 | 3 |
| HQ-LK4T | 12.95 | 2700*1950*2850 | 700*1260 | 600 | 2,400,000 | 3.5 | 4 |
| HQ-LK6T | 14.7 | 3100*2100*3100 | 800*1360 | 1000 | 3,600,000 | 5 | 6 |
| HQ-LK8T | 19 | 3150*2100*3050 | 900*1450 | 1200 | 4,800,000 | 7.2 | 8 |
| HQ-LK10T | 12.6 | 3250*2600*3150 | 900*1450 | 1500 | 6,000,000 | 9.5 | 10 |
| HQ-LK12T | 29.2 | 3500*2350*3250 | 1000*1450 | 1800 | 7,200,000 | 11 | 12 |
| HQ-LK16T | 43 | 3650*2600*3350 | 1200*1550 | 2400 | 9,600,000 | 14 | 16 |
| HQ-LK18T | 43 | 3650*2350*3350 | 1200*1550 | 2700 | 10,800,000 | 15.5 | 18 |
| HQ-LK20T | 43 | 3750*2450*3350 | 1200*1550 | 3000 | 12,000,000 | 18.5 | 20 |
| Note: 1,Suitable for size 6-10MM wood pellet, moisture: <15% 2,If technical parameters change, no further notice! | |||||||
Cooperation Method
1.Equipment Purchase and Sale.
2.Equipment Agency or Agency Sales.
3.Contract energy management.
Our Service
